Legrand WSR320-S User Manual
Page 2
Wiremold
U.S. and International:
60 Woodlawn Street • West Hartford, CT 06110
1-800-621-0049 • FAX 860-232-2062 • Outside U.S.: 860-233-6251
Canada:
570 Applewood Crescent • Vaughan, Ontario L4K 4B4
1-800-723-5175 • FAX 905-738-9721
1 009 456 0710
© Copyright 2010 Legrand/Wiremold All Rights Reserved
EDGE MOUNT
NOTE: This part is not needed
for edge mounting.
Step 2. Remove Hole Mount (C).
Step 3. Assemble Edge Mount (D).
Step 4. Attach Edge Mount to Desk.
Step 5. Attach Power Unit to Mount.
Snap together
two tabs
Step 1. Remove Mounting Plate (A) from Power Unit (B).
Depress
Tab
Depress
Tab
Power Unit
(B)
Mounting
Plate (A)
Hole Mount
(C)
Edge Mount
(D)
