Legrand DS4000 Obstacle Avoidance User Manual

Page 5

Text mode
Original mode

Step 5. Measure Cover distance from top of Divider.

Step 7. Snap on Cover.

Step 8. Install Elbow Cover and Inside Corner Trim.

Measure

Step 6. Trim Cover on side as shown.

Cut

NOTE: To remove Cover or install a Tamper Resistance Kit, refer to page 6 of this instruction sheet.
