Legrand 4000 Series Two-Piece Metal Raceway User Manual
4000 series two-piece metal raceway, 4001da
4000 Series
Two-Piece Metal Raceway
I N S TA L L AT I O N I N S T R U C T I O N S
Installation Instruction No.: 41403R2 – Updated July 2004
UNSHIELDED
SHIELDED
TWISTED PAIR
TELEPHONE
TWISTED
TYPE
24 AWG, 4-PAIR
24 AWG, NO. OF PAIRS
COAXIAL
TWINAXIAL
PAIR
FIBER OPTIC
TWO STRAND (DUPLEX)
CAT. 5
CAT. 3
2
3
4
25
RG58/U
RG59/U
RG62/U
RG6/U
100 OHM
TYPE 1
TYPE 2
TYPE 3
MULTIMODE, 62.5/125µm
O.D. inches
0.220
0.190
0.140
0.150
0.190
0.410
0.195
0.242
0.242
0.270
0.330
0.390
0.465
0.245
0.190
O.D. [mm]
[5.6]
[4.8]
[3.6]
[3.8]
[4.8]
[10.4]
[5.0]
[6.1]
[6.1]
[6.9]
[8.4]
[9.9]
[11.8]
[6.2]
[4.8]
40% fill, divided
37
50
92
80
50
10
47
30
30
24
16
11
8
29
49
40% fill, undivided
75
100
183
161
100
21
95
62
62
49
33
23
16
60
100
4000 RACEWAY WIRE FILL CAPACITIES FOR DATA/COMMUNICATIONS
NUMBER OF CONDUCTORS (40% FILL)
WIRE SIZE
O.D.
WITHOUT DEVICES
WITH DUPLEX / RECT. DEVICES
WITH SURGE / GFCI DEVICES
LARGE SINGLE RECEPTACLES
THHN/THWN
inches
[mm]
1.59 in
2
[1025mm
2
]
2.30 in
2
[1485mm
2
]
3.00 in
2
[1935mm
2
]
UNDIVIDED
DIVIDED
UNDIVIDED
DIVIDED
UNDIVIDED
DIVIDED
UNDIVIDED
DIVIDED
14
AWG
0.111
[2.8]
296
127
165
78
107
49
49
20
12 AWG
0.130
[3.3]
216
93
120
57
78
36
36
15
10
AWG
0.164
[4.2]
136
58
76
36
49
22
22
9
8 AWG
0.216
[5.5]
78
33
43
20
28
13
13
5
6 AWG
0.254
[6.5]
56
24
31
15
20
9
9
3
4
AWG
0.324
[8.2]
34
15
–
–
–
–
–
–
3 AWG
0.352
[8.9]
29
12
–
–
–
–
–
–
2
AWG
0.384
[9.8]
24
10
–
–
–
–
–
–
4000 RACEWAY WIRE FILL CAPACITY FOR POWER
• Use No. 8 (5/16", 7.9mm head size) flat head fastener or equivalent to
mount base to surface.
• Utiliser une attache à tête plate de calibre 8 (tête de 7.9mm, 5/16" po.)
ou une fixation équivalente pour assujettir le tube guide-fils et les rac-
cords à la surface de montage.
• Use un sujetador de cabeza plana No. 8 (tamaño de cabeza: 7.9mm,
5/16" de pulgada) o su equivalente para unir la canalita y los accesorios
a la superficie de montaje.
• Grounding: Use ground location when provided or install a suitable
ground lug, ring terminal or locknut and ground bushing.
• Mise à la terre: Utiliser l’emplacement de terre prévu ou poser le
matériel qui convient: patte de mise à la terre, cosse circulaire à oeil ou
écrou de blocage et manchon de terre.
• Conexión a tierra: Use un localizador de tierra cuando se proporcione o
instale una orejeta de tierra, anillo terminal o contratuerca y cojinetes de
tierra apropiados.
18"
[45.7cm]
30"
[76cm]
4000B-10
640B
640C
4000WC
4010B
4010D
4011
4000C075 = 12" [30.5cm]
4000C135 = 18" [45.7cm]
4000C195 = 24" [60.9cm]
4000C315 = 36" [91.4cm]
4001DA
4001DA
4000C
Precut
Covers
4014A
4015
4015D
4018
Wiremold Electrical Systems conform to and should be
installed and properly grounded in compliance with
requirements of the current National Electrical Code, Canadian
Electrical Code or codes administered by local authorities.
All electrical products may represent possible shock or fire
hazard if improperly installed or used. Wiremold electrical
products are UL Listed to U.S. and Canadian safety
standards, made for interior use only, and should be installed
in conformance with current local and/or the National
Electrical Code.
