Legrand 3000 Series Medium Steel Prewired Raceway Fiber Optic Inserts User Manual
Installation instructions, Side “a” face up. side “b” face up
4011/15RI
4011DRI
4015DRI
4017/18RI
INSTALLATION
INSTRUCTIONS
Wiremold Electrical Systems conform to and should be installed and properly
grounded in compliance with requirements of the current National Electrical
Code, Canadian Electrical Code or codes administered by local authorities.
All electrical products may represent possible shock or fire hazard if improperly
installed or used. Wiremold electrical products are UL listed. Made for interior
use only and should be installed in conformance with current local and/or the
National Electrical Code.
4011 Flat Elbow 40% Fill
4017& 4018 Elbows 40% Fill
4015D & 4015 Tee Fitting 40% Fill
Cable/Wire Size
O.D.
4011DRI Divided
4011/15RI Undivded
4017/18RI Divided
4017/18RI Undivded
4015DRI Divided
4011/15RI Undivded
Power Wiring
2 Awg
0.384
11
21
6
11
6
16
THHN/THWN
4 Awg
0.324
15
30
8
15
9
23
6 Awg
0.254
24
48
13
25
14
37
8 Awg
0.216
34
67
18
35
20
51
10 Awg
0.164
68
136
36
71
40
104
12 Awg
0.130
107
214
56
112
63
163
14 Awg
0.111
145
288
75
151
85
220
Unshielded
Cat. 5 UTP
0.22
33
66
17
34
19
50
Twisted Pair
Cat. 3 UTP
0.19
44
88
23
46
26
67
2 Pair
0.14
81
162
42
85
48
124
Telephone
3 Pair
0.15
71
141
37
74
42
108
4 Pair
0.19
44
88
23
46
26
67
25 Pair
0.41
9
19
5
10
6
14
RG58/U
0.195
42
84
22
44
25
64
Coaxial
RG59/U
0.242
27
54
14
28
16
41
RG62/U
0.242
27
54
14
28
16
41
RG6/U
0.27
22
44
11
23
13
33
TwinAxial
100 Ohm
0.33
15
29
8
15
9
22
Shielded
Type 1 STP
0.39
10
21
5
11
6
16
Twisted Pair
Type 2 STP
0.465
7
15
4
8
4
11
Type 3 STP
0.245
27
53
14
28
16
40
Fiber ZipCord
0.11
132
263
69
137
78
201
Fiber Optic
Round Fiber 2 Strand
0.18
49
98
26
51
29
75
Round Fiber 4 Strand
0.19
44
88
23
46
26
67
Round Fiber 6 Strand
0.21
36
72
19
38
21
55
Raceway Wire and Cable Fill Capacity When Using 4000 Radius Inserts
4011/15RI when used with 4011 undivided elbow.
4011/15RI when used with 4015 undivided tee.
4011/15RI
Typical Installations
4011
4015
4011/15RI
Side “A” face up.
Side “B” face up.
4011DRI when used with 4011 for divided elbow.
4011/15RI
