Legrand WKD Pro Series Modular Afterset User Manual
Page 7
TEMPLATE
– Used to locate center of 2 1/2" [64mm] diameter holes cut in duct.
NOTE: Holes shown are not 2 1/2" [64mm],
however center locations are correct.
4 1/8"
[105mm]
4 1/8"
[105mm]
CAUTION: When printing copies of this
template, please be sure
template is scaled correctly
and is the correct size once
it is printed.
