Within this workstation (grey background), there is one TS master console.
You can configure this console as a master console (see
Chapter 3.5.2.4 ).
Within the TS workstation, the TS master console is the only one that has a
keyboard and mouse connected. Furthermore, this console displays
information that identifies which TS console within the workstation currently has
the keyboard and mouse assigned to it.
Each UCON can become the TS master console or a TS slave console.
On the other hand, the remaining consoles are informed that the keyboard and
mouse has been assigned to this console. This display option can also be
activated (see
Chapter 3.4 ). The keyboard and mouse assignment identifies
the console in the TS workstation to which the keyboard and mouse connected
to the TS master console are currently assigned.
Switching either takes place via hotkeys or it can be combined with the optional
IP switching function. These hotkeys can be configured (see
Chapter 3.3 ).
To provide visual feedback regarding the monitor to which the keyboard and
mouse are currently assigned, it is also possible to attach LEDs connected to a
UCON to the respective monitors.
3.2 Rights
Every user logged on to the system has the rights required to carry out the
functions described in this chapter.
3.3 Assigning Hotkeys to the TS Function
A switching process must be carried out in order to change the keyboard and
mouse assignment to another console within a TS workstation. This switching
process takes place via hotkeys. The hotkeys for the TS function are
deactivated by default. Therefore, you should define the desired hotkeys
before configuring the workstation. To do so, proceed as follows:
1. Open AdonIS using the hotkey combination CTRL + NUM (default).
2. Press the F11 key; the Configuration menu opens.
3. Move to the entry System with the mouse or the cursor keys on your
keyboard and press ENTER .
4. In the open System Menu, select the entry TradeSwitch Key with
the mouse or the arrow keys on your keyboard.
