PT-1954 Fuel Point Parts Manual · August 2005 Page 3-5
Fuel Point Reader, C06699 - Side View Parts List
* Indicates that this part is a subpart of the preceding part without an asterisk.
** Indicates that this part is a subpart of the preceding part with an asterisk.
Item Part No. Description
1 C06767 Door Assy.
2 *035009 Lock w/Key
3 *C34753 Lock Cam
4 C06790 Mounting Kit (Not Shown)
5 C35618 Mounting Brkt.
6 C06778 Cable Assy. 115VAC Power Input (Not
Shown)
7 C06779 Cable Assy. RS-485 Comm Input (Not
Shown)
8 C08875 Gasket (Not Shown)
9 C06783 PCB Assy., I/S Barrier
10 C02446 Line Filter
11 C35668 Bracket P/S Hold Down
12 C06726 Cable Assy., Heater 115VAC
13 C06797 Power Supply, 5VDC
NOTE: Items 9, 10, 11, 12, & 13 are subparts of item 4 C06698 from front view pages.
