58
Selecting "4: QRCODE" on the SET SYSTEM menu
calls up the screen shown at left.
Highlighted is the current setting.
1 INVERT : Activates or deactivates the
black-and-white inverted la-
bel reading function.
2 DECODE LEVEL : (Not applicable.)
3 MARKER : Sets the marker ON/OFF
mode.
4 VIEW FINDER : Turns the view finder on or
off.
5 OPTION DATA : Selects whether or not op-
tion data will be added to the
tail of 2D code data read.
6 ITF : Sets the minimum number of
digits to be read for ITF.
7 CODABAR : Sets the minimum number of
digits to be read for Codabar.
Select a desired item by using the numerical keys
or M1 and M2 keys, and then select a desired
setting by using the SF+M1 and SF+M2 keys.
To increase the decode level, press the SF+M2
keys; to decrease it, press the SF+M1 keys.
To increase the number of digits to be read for ITF
and Codabar, press the SF+M2 keys; to decrease
it, press the SF+M1 keys.
Press the ENT key.
To return to the SET SYSTEM menu, press the C
key.
[4.4] Setting the special scanning parameters
Black-and-white inverted label reading function (INVERT)
This function makes it possible to read white bars on a black background.
When this function is activated, the BHT-100Q cannot read codes other than QR
codes.
