Flowserve VTP Wet Pit - Manual (Page 71)

VERTICAL TURBINE PUMPS (VTPS) CENTRIFUGAL PUMPS ENGLISH 71569224 – 10-13
Page 71 of 76 flowserve.com
369 Ring flow
370 Sleeve stuffing box 2450 Shaft sleeve
371 Oring stuffing box sleeve 4610.# O-ring
372 Stud threaded barrel 6572.# Stud
373 Nut hex barrel 6581.# Hexagon nut
374 Oring barrel 4610.# O-ring
377
Gasket suction f/adapter
column
4590.# Gasket
378 Gasket discharge 4590.# Gasket
379
Screw cap hex/head
discharge
6570.# Screw
380 Nut hex discharge 6581.# Hexagon nut
381 Screw cap hex/head motor 6570.# Screw
382 Nut hex motor 6581.# Hexagon nut
383 Cap lubricator tank
384 Band lubricator tank
385 Bolt stove f/tank oiler assy.
386 Nut hex f/tank oiler assy. 6581.# Hexagon nut
387
Lubrication line f/tank oiler
assy.
3840 Lubrication line
388
Fitting compression elbow
f/tank oiler assy.
389
Fitting compression straight
f/tank oiler assy.
390 Bearing assembly (ag)
392 Nipple pipe pre-lube
393 Valve gate pre-lube
394 Pin lifting f/head 2923.# Pin
395 Ring retaining f/head
396 Clip safety f/tube nut
397 Screw cap hex/head tube nut 6570.# Screw
399
Adapter column flanged to
flanged
1140 Discharge casing
400
Screw cap hex/head adapter
column
6570.# Screw
401 Nut hex adapter column 6581.# Hexagon nut
402
Bearing rubber cutless
discharge case
3300.# Bearing, bushing
403
Adapter column flanged to
threaded
1140 Discharge casing
405 Oring ingerseal 4610.# O-ring
409 Adapter driver f/m head
412 Stud threaded base plate 6572.# Stud
413 Nut hex base plate 6581.# Hexagon nut
414 Plug pipe head pre-lube 6578.# Threaded plug
415
Plug pipe head inspection
hole
6578.# Threaded plug
416 Plug pipe head pressure tap 6578.# Threaded plug
417
Screw cap hex/head coupling
guard
6570.# Screw
