1
Introduction
9
I/O Connectors
BIOS
Energy Efficient
Design
Damage Free
Intelligence
Temperature
Humidity
PCB
• 2 connectors for 4 additional external USB 2.0/1.1 ports
• 1 connector for an external COM port
• 1 Digital I/O connector
• 1 front audio connector for line-out and mic-in jacks
• 1 CD-in internal audio connector
• 1 S/PDIF-in/out connector
• 1 connector for IrDA interface
• 4 Serial ATA connectors
• 1 40-pin IDE connector
• 1 floppy connector
• 1 24-pin ATX power connector
• 1 4-pin 12V power connector
• 1 front panel connector
• 3 4-wire fan connectors
• Award BIOS
• 8Mbit SPI flash memory
• Suppor ts ACPI specification and OS Directed Power Manage-
ment
• Supports ACPI STR (Suspend to RAM) function
• Wake-On-Events include:
- Wake-On-PS/2 Keyboard/Mouse
- Wake-On-USB Keyboard/Mouse
- Wake-On-LAN
- Wake-On-Ring
- RTC timer to power-on the system
• System power management supported
• CPU stopped clock control
• Microsoft
® /Intel ® APM 1.2 compliant
• Soft Power supported - ACPI v2.0 specification
• AC power failure recovery
• Monitors CPU/system temperature and overheat alarm
• Monitors Vcore/VBAT/3VSB/12V/1.25V/1.8V/5V voltages and failure
alarm
• Monitors CPU/2nd/system fan speed
• Read back capability that displays temperature, voltage and fan
speed
• Watchdog Timer function
• Operating: 0
o C to 60 o C
• Non-operating: -40 o C to 85 o C
• Operating: 10% to 90%
• 4 layers, microATX form factor
• 24.4cm (9.6") x 22.5cm (8.86")
