BIOS Setup
IDE HDD Auto-Detection
Detects the parameters of the drive. The parameters will automati-
cally be shown on the screen.
IDE Channel 0 Master/Slave and IDE Channel 1 Master/Slave
If you select ”Auto”, the BIOS will auto-detect the HDD & CD-
ROM drive at the POST stage and show the IDE for the HDD &
CD-ROM drive. If a hard disk has not been installed, select “None”.
Access Mode
For hard drives larger than 528MB, you would typically select the
LBA type. Certain operating systems require that you select CHS or
Large. Please check your operating system’s manual or Help desk on
which one to select.
Capacity
Displays the approximate capacity of the disk drive. Usually the size
is slightly greater than the size of a formatted disk given by a disk
checking program.
The settings on the screen are for reference only. Your version may not be
identical to this one.
IDE Channel 0 Master and IDE Channel 1 Master
To configure the IDE drives, move the cursor to a field then press
. The following screen will appear.
IDE HDD Auto-Detection
IDE Channel 0 Master
Access Mode
Capacity
Cylinder
Head
Precomp
Landing Zone
Sector
Phoenix - AwardBIOS CMOS Setup Utility
IDE Channel 0 Master
Item Help
Menu Level XX
To auto-detect the
HDD’s size, head... on
this channel
