28 All Sport Applications
Auto Horn
Use the Auto Horn key (Figure 26) to set whether the horn sounds
automatically when the main clock reaches 0:00.
Applies to: Basketball, Clock/Score, Football, Segment Timer
Note: For Football, the Auto Horn is an alternate function.
Display Action
Press and then press <1> or <2> to
select ON (default) or OFF.
When Auto Horn is enabled, a small ‘h’ will appear under the clock
direction arrow on the LCD. Figure 27 shows an example where the
clock is counting down and the auto horn is enabled.
Figure 26: Auto
Horn Key
Figure 27: Auto
Horn Indicator
AUTO HORN-ON {
1-ON, 2-OFF
