All Sport Applications 27
Display Action
This key is typically implemented as an alternate
function. After the main clock has been stopped, press
followed by to set the direction of the
clock.
Press <1> or <2> to select UP or DOWN (default).
The current direction of the clock is shown by an arrow
on the LCD.
Dim (Alternate Function)
The Dim key (Figure 24) sets the dimming level (brightness) of the
display.
Applies to: Baseball, Basketball, Clock/Score, Football, Play Clock/
Pitch Timer, Sand Volleyball, Segment Timer, Tennis, Volleyball
Display Action
NN = current level
NONE = bright <0>
90% = <1>
80% = <2>
70% = <3>
60% = <4>
50% = <5>
40% = <6>
30% = <7>
20% = <8>
10% = <9>
This key is typically implemented as an alternate
function Press followed by to view the
current dimming level.
Press <0> through <9> to change the dimming level.
Press to save.
Press to cancel and resume normal
operation.
Manual Horn
Press the key (Figure 25) to sound the horn.
The horn sounds as long as the key is pressed and stops sounding
when the key is released.
Applies to: Basketball, Clock/Score, Football, Remote Start/Stop,
Sand Volleyball, Segment Timer, Tennis
Figure 24: Dim Key
Figure 25: Manual
Horn Key
MAI N CLOCK-DOWN}
1-UP 2-DOWN
DI MMI NG
LEVEL(O-9): NN%
