Delfield Nordic Zone Cold Food Bars - Manual (Page 6)

Nordic Zone Salad Bar Service and Installation Manual
For customer service, call (800) 733-8829, (800) 773-8821, Fax (989) 773-3210, www.delfield.com
6
Nordic Zone Salad Bar Service and Installation Manual
7
For customer service, call (800) 733-8829, (800) 773-8821, Fax (989) 773-3210, www.delfield.com
WIRING DIAGRAM 207”
ST
AINLESS STEEL ENCLOSURE
LIGHT ON/OFF SWITCH
NEUTRAL
L1
GND
WHITE
RED
BLUE
XF
FUSE OFNM-15
X1
X2
RED
WHITE BLACK
HF
FUSE IKTK-R-5
H4
H2
H3
H1
H1
FUSE IKTK-R-5
BLACK BLACK
BLUE BLACK BLUE
120v TO 24v TRANSFORMER
HEA
TING ELEMENTS
GREEN
END LAMP
WHITE BLACK
LAMP 1
LAMP 2
Y Y
R R B B
R B B Y Y R
BALLAST
, 120v INPUT
, 227v OUTPUT
GREEN WHITE BLACK
RAIL F
AN
RAIL F
AN
RAIL F
AN
RAIL F
AN
RAIL F
AN
RAIL F
AN
RAIL F
AN
RAIL F
AN
(4) TO (8) F
AN MOTORS
WHITE BLACK
WHITE RED
SOLENOID
THERMOST
AT
FAN
M
OT
OR
1
2
3
4
5
WHITE
RED
BLACK
MAIN ON/OFF SWITCH
NOTE: each 1/2 section of the
salad bar requires separate elec-
trical connections. This wiring
diagram represents a 1/2 section.
