Digicast Media Router Serial IP (SIP): CMR-5910 (MG-SIP) & CMR-5920 (MR-SIP) Revision A
Device Management via User Interfaces - CMR-5920 (MR-SIP) MN/MDRTRIPDC.IOM
To modify code via Telnet:
Step Procedure
1 Start up Solarwinds TFTP server – Ensure configuration as described
previously.
2 Ensure that the code provided by CEFD is located in the TFTP Root
directory.
3 Start up Telnet client and initiate a session with the MR-SIP as
described in the Terminal Interface section.
4 Select ‘A’ for Administrative.
5 Select ‘D’ for Download.
6 Enter the IP address of the TFTP server and wait for the message
“Upgrade complete. Press any key to continue.”
This code modification process can also be conducted via the Web Interface, under the
Administrative page, or the Terminal Interface under the Main Menu.
5.6 Simple Network Management Protocol (SNMP) (Future)
Simple Network Management Protocol (SNMP) has not been enabled on this product and
is planned as a future release. However, when enabled, SNMP allows an SNMP Manager
such as OpenView or Castle Rock to be used to remotely manage the MR-SIP in an
automated fashion.
The MR-SIP supports SNMP versions 1 and 2 (SNMPv1 and SNMPv2). SNMP version
3 (SNMPv3) will be supported in future releases. Two types of Management Information
Bases (MIBs) are supported: MIB II and private MIB.
MIB II is the default MIB that is used to gather generic information about the unit, such
as system ‘up’ time, packets sent or received on an interface, etc. MIB II is designed for
only read access, not write access. To read and write configuration parameters over
SNMP requires a private MIB. The private MIB allows parameter s to be set on the
Web, Terminal or Telnet interfaces.
Under heavy traffic conditions, the TFTP transfer may take several
minutes. The transfer process reported by Solarwinds may show
greater than 100% transferred, but this is a normal condition. Be
patient and allow the transfer to take place.
IMPORTANT
The elements Object Identifiers (OIDs) of the MR-SIP’s MIB will be listed in the
appendix of a future revision of this manual. CEFD has been assigned an SNMP
designator by the IEEE, which will be found in all elements of the MR-SIP’s MIB.
NOTE
The assigned designator for CEFD (enterprise OID) is 1.3.6.4.1.18723.
5-18
