Digicast Media Router Serial IP (SIP): CMR-5910 (MG-SIP) & CMR-5920 (MR-SIP) Revision A
Installation & Initial Configuration MN/MDRTRIPDC.IOM
2.4 Initial Configuration
The initial configuration involves setting up the IP parameters via the terminal cable.
Once the IP parameters have been configured, the terminal cable can be removed. The
terminal cable should be stored in a known location, since it may be needed in the future.
To configure the IP parameters:
Step Procedure
1 Using a terminal emulator on a PC such as HyperTerminal™ or
TeraTerm™, set up the communication port as follows:
• 38,400 BAUD
• 8 Data Bits
• 1 Stop Bit
• No Parity
• No Flow Control
2 Press the key on the PC – the device’s menu should be
displayed.
3 Press “N” for Network Menu.
4 Press “I” for the IP Address. Enter the IP Address and select .
5 Press “M” for the Subnet Mask. Enter the Subnet Mask and press
.
6 Press “G” for the Default Gateway IP Address. Enter the Default
Gateway Address and press .
7 Press “S” to save the parameters.
8 Press “Y” to confirm the saving of parameters.
9 Press “X” to exit to the main menu.
For the MG-SIP only:
10 Press “E” to configure the egress port.
11 Press “M” to configure the egress clock source as external or internal.
12 Press “R” to configure the egress clock rate in bits per second (bps) and
press .
13 Press “S” to save the parameters.
14 Press “Y” to confirm the saving of parameters.
15 Press “X” to exit the menu.
At this point, the device has been configured for full operation and the terminal cable
may be removed. The RS-422/RS-530 cable may now be safely attached to the DB-15
male connector marked
RS-422 . For continued operation, the device may be managed via
the Terminal Interface; however, it is recommended to use the Web Interface for ease of
management.
2-3
