A.2 web interface – Comtech EF Data CMR-5910 Manual User Manual
Page 68
Digicast MEdia Router Serial IP (SIP): CMR-5910 (MG-SIP) & CMR-5920 (MR-SIP)
Revision A
Software Upgrade
MN/MDRTRIPDC.IOM
A.2 Web
Interface
Access the
Administrative Configuration
page (Figure A-1):
a) In
the
Update Firmware
section, enter the
Unit TFTP Server IP Address
.
b) Select
Application
or
FPGA
for the
Image Type
to be upgraded.
c) In the second
Login Required
section, enter a valid username and password,
then select
Update
. The software update will begin to download.
IMPORTANT
Do
NOT power the unit down during the upgrade process.
d)
When the update is complete, the message “
Press any key to continue
”
will be displayed.
e)
When the unit has been upgraded, reset the unit by entering a valid username
and password in the first
Login Required
section and selecting
Reset Unit
.
Figure A-1. TFTP Download (via Web Interface – MG-SIP shown)
A–2
