Chapter 5. DEVICE MANAGEMENT
VIA USER INTERFACES:
CMR-5920 (MR-SIP)
5.1 Introduction
Management of the CMR-5920 Serial IP Router (MR-SIP) is simple and intuitive. There
are a variety of ways to specficially configure and manage the MR-SIP:
•
Web Interface via a LAN-based desktop Web browser
•
Terminal Interface via direct connection to a PC’s asynchronous serial port
•
Telnet Interface via a LAN
•
TFTP for remote terminal upgrades
•
SNMP Private MIB and MIB II (Future)
5.2 Web Interface
The Web Interface, operating under standard HyperText Transport Protocol (HTTP), is
used to communicate with and command the MR-SIP via a HyperText Markup
Language-based Graphical User Interface (GUI). To utilize the Web Interface, a LAN
connection must exist between the PC with a Web browser and the MR-SIP.
Once a valid IP Address, Subnet Mask and Default Gateway have been entered into the
MR-SIP, activate a Web browser on the desktop then enter the IP address of the MR-SIP
into the URL field as shown below. If the port number has been modified from the
Standard 80 via the Terminal Interface, then the port number must be appended with a
colon to the IP address.
Figure 5-1. Connecting to the MR-SIP
5-1
