External connections 8-3
Revision C2005-2 C-Type
;17 3URGXFHU·V#2XWSXW
* Line requires connection to GND to select function
7DEOH#7=#580ZD\#µ'¶0W\SH#IHPDOH#FRQQHFWRU#RQ#UHDU#RI#³FRPPXQLFDWLRQV´#
PRGXOH
PIN 1 PRODUCER TO TALKBACK 1 SELECT *
PIN 14 PRODUCER TO TALKBACK 2 SELECT *
PIN 2 PRODUCER TO AUX 1 SELECT *
PIN 15 PRODUCER TO AUX 2 SELECT *
PIN 3 PRODUCER TO AUX 3 SELECT *
PIN 16 PRODUCER TO AUX 4 SELECT *
PIN 4 PRODUCER TO FOLDBACK SELECT *
PIN 17 PRODUCER TO PLAYBACK SELECT *
PIN 5 PRODUCER TO MUSICAL DIRECTOR SELECT *
PIN 18 PRODUCER’S CONTROL LINE *
PIN 6 PRODUCER’S O/P, LEFT (+)
PIN 19 PRODUCER’S O/P, LEFT (–)
PIN 7 PRODUCER’S O/P, RIGHT (+)
PIN 20 PRODUCER’S O/P, RIGHT (–)
PIN 8 GND
PIN 21 GND
PIN 9 0V
PIN 22 0V
PIN 10 PRODUCER’S MICROPHONE (+)
PIN 23 PRODUCER’S MICROPHONE (–)
