User Manual
29
5.8 Record search
You could enter into [Record Search] menu from Context-Sensitive menu conveniently and quickly and
search/playback the record histories. We introduced Record search details previously in Section 5.3.3.
5.9 Manual Record
You can start manual record function, or you also can click [ ] button on the Front panel or Remote
controller to activate manual record. Please stop record manually once you activate manual record.
5.10 Stop record
To stop record quickly, please press [Stop] button on the remote controller.
5.11 PIP Mode
You can display a Picture-in-Picture in live mode. PIP has two display modes, including 1X1 display mode
and 1X2 display mode.
5.12 Mute
Click the [ ] icon, or press button on the front panel and Remote controller to control the mute of
MDVR shown as Picture 5-7.
Chapter 6- Appendix
6.1 Record Alarm setting
Please refer the below matrix: “ ĵ” stand for “only alarm but no record”; “AMR” stand for “alarm record”;
“NLR” stand for “normal record”; and “NOR” stand for “ no record”. Once alarm is triggered, alarm icon will
occur, and when many alarms are triggered, alarm remarks will occur on the screen.
Record alarm setting Alarm icon
Record Mode
Record after
power on
Scheduled recording
Manual Record
AMR NLR NOR
Alarm
mode
MD alarm AMR AMR NLR ĵ NLR
I/O triggered alarm AMR AMR NLR ĵ NLR
HDD loss, HDD Full ĵ ĵ ĵ ĵ ĵ
Video Loss Video Loss ĵ ĵ ĵ ĵ ĵ
List 6-1
In the record mode, [ ] icon or [ ] icon will appear on the screen. But when [ ] icon and [ ] icon appear
on the screen that means a motion alarm is triggered. When [ ] icon appears on the screen, that means HDD alarm
1x1 display mode 1x2 display mode
