Bolide SVR9000DMOB_W User Manual
Page 22
User Manual
18
1. Set your net type to Static;
2. Set media port number (such as 9000), and the port need to be forwarded to a router.
3. Input web port number (such as 8080), and the port need to be forwarded to a router;
4.
Input a specified IP address to [IP address] column;
5. The Subnet Mask, gateway and DNS server should be consistent with your router’s
configurations.
6.
Input DNS address. Please check router firstly. The setting should be consistent with router’s
7.
Click [Apply] button
8.
Now you could remotely visit the DVR via IP
http: // public net IP: web port (such as: 8080)
http: //intranet IP: web port (such as: 8080 - only use for Intranet)
When selecting PPPoE form the Type, user can input user name and password provided by ISP and
set Media and Web port. And now you can visit your remote DVR by using the IP address captured after
registering a domain name and web port and connect to your DVR via public network.
DDNS (Dynamic DNS) is a service that register a domain name and the floating IP address with the
DDNS server so that the domain name can be routed to the IP address even if the IP address is changed
in a dynamic IP system.
Note:
User can visit a remote DVR by using DDNS on above three types (Static, DHCP and PPPoE)
You can apply for a DDNS account for free at the web
www.3322.org
or
www.dyndns.org
; or
You can register on DVR2009.3322.org or dyndns.org website and get a domain name, user name, and
password.
When selecting WCDMA (CDMA2000), user can input APN,
user name, password and DNS etc provided by ISP, then click
After restarting, you can visit a remote MDVR.
Picture 5-21
Picture 5-22
Picture 5-23
