Menu Parameter
Description
OLV PARAMETER Symbol Contrast Default: -1
No checking
0-100
The value must be higher than or equal to the set limit.
OLV PARAMETER PCS Default: -1
No checking
0-100
The value must be higher than or equal to the set limit.
OLV PARAMETER R (White) Default: -1
No checking
0-100
The value must be higher than or equal to the set limit.
OLV PARAMETER R (Black) Default: -1
No checking
0-100
The value must be lower than or equal to the set limit.
OLV PARAMETER Ratio Default: -1
No checking
0-100
The value must be higher than or equal to the set limit.
OLV PARAMETER ANSI
Symbolgrade
or ANSI Symb.
Grade Default: -1
No checking
0 – 40
The measured value must be higher than or equal the
set limit.
0 – 4
ANSI Grade F
5 – 14 ANSI Grade D
15 – 24 ANSI Grade C
25 – 34 ANSI Grade B
35 – 40 ANSI Grade A
For most applications, only set this parameter.
The previously listed parameters are checked
automatically according to the ANSI grade.
OLV PARAMETER Dist. head-beam Default: 8mm
Sets the distance between the laser beam and the
printhead.
6mm – 18mm
