Wood Stove Rear Fan 2 Installation Instructions
99000118
Page 4 of 5 17601791.docx - 5/2/13 © Travis Industries, Inc.
1750 Installation Instructions
d
f
g
Attach the wires from
the thermodis k to the
wires from the blower.
Attach the blower to the s tove with the
three s crews included with the blower.
3/8" W rench
h
R emove thes e two knock-outs on
the bottom of the s tove (us e a
s crewdriver to pry them out).
a
P lug the blower in. Do not route the power cord under or over the s tove or in a
location where it may become damaged.
P os ition the blower near the rear of the s tove. T uck all exces s wire into the
blower box, making s ure it does not contact any moving parts . Make s ure when
ins talling the blower, thes e wires do not become loos e.
b
c
As s embly
As hlip
W edge the s nap dis k into
the convection channel.
extender, if neces s ary, s o
the s nap dis k contacts the
firebox.
T wis t the wires together,
feed them through the
convection chamber, out
the knockout, and attach to
the leads on the blower.
Dis connect thes e wires
to ins tall the extender
(re-connect after the
extender is attached).
P lace the s nap dis k as s embly over the s nap dis k extender
(included with the s tove) and bend thes e tabs to s ecure.
Bend the legs on the
Snap Disk
Extender
Snap Disk
e
Attach the rheostat box to the
underside of the stove behind the
left front leg. Magnets hold it in place.
