Wood Stove Rear Fan 2 Installation Instructions
99000118
Page 3 of 5 17601791.docx - 5/2/13 © Travis Industries, Inc.
3. Place the blower near the bottom rear edge of the stove. Attach the quick-connects from the snap disk
assembly to the quick-connects on the blower. Push any slack wire into the blower box. Attach the
blower following the directions below.
4. Attach the rheostat and rheostat mounting bracket to the underside of the stove, behind the left front leg.
Magnets hold it in place.
The blower is shown in the photo below.
E ndeavor & L iberty:
F eed the two wires from
the blower through this
hole before attaching the
quick-connects .
A ll Other Models :
F eed the wires
directly upwards
NOT E :
P rior to attaching the blower, tuck all exces s
wire into the area ins ide the blower.
T he blower attaches to the s tove with the three
included s crews . Us e a 3/8” s ocket driver or wrench.
HINT :
Attach the s crews to the back of the s tove prior to
attaching the blower. T his will cut the threads and
eas e ins tallation.
P lug the power cord into
a 110 V . outlet after
ins talling the blower.
NOT E :
P rior to attaching the
blower, tuck all exces s
wire into the area ins ide
the blower.
a
Attach the quick-connects
leading from the s nap dis k to the
quick-connects from the blower.
b
c
Attach the rheostat box to the underside
of the stove behind the left front leg.
Magnets hold it in place.
