Sorensen SLM-1 Chassis Operation
3.4.1 EDIT MODE
To enter the EDIT mode of the Sequence function, press State3 + State4 keys
simultaneously (State 3 and State 4 LEDs are On, indicating Auto Sequence function
is now active). Use the BANK up/down keys to select the sequence to be edited,
then press the STORE key to begin the editing process.
The EDIT MODE flow chart is described below:
• Nine Auto Sequences (n1-n9) can be edited within the SLM chassis.
• Each Auto Sequence has up to 16 test steps, where each step is pulled from
any of 5 Stored memory sets for AC modules (in the 5 State locations), or
150 Stored memory sets for DC modules (30 Bank memory locations in each
of 5 State locations).
• Each test step has t1 (test time, or duration of test step) and t2 (delay time),
the unit of time is 100mS, the range is 0.1S - 9.9S in 100mS resolution. SLM
chassis will check each module GO/NG at the end of t1 (test time), the next
step will be started after t2 (delay time).
• The test step sequence can include up to 16 steps, and can be terminated by
pressing the EXIT key (State 2) if fewer than 16 steps are required.
3.4.2 TEST MODE
To enter the TEST Mode of Sequence function, press State 3 + State 4 keys
simultaneously; (State 3 and State 4 LEDs are On, indicating Auto Sequence
function is now active). Use the BANK Up/Down keys to select the sequence test to
be run, then press the START key to run the test sequence.
• After pressing the START key, the SLM chassis controls the installed module
to recall the memory stored in Auto-sequence (n1~n9).
• Each test sequence starts from (Step 0 - t1 - t2), then (step 1 - t1 - t2), and so
on until either it completes the last step or is stopped by pressing the EXIT
(State 2) key.
• The two-digit BANK LED will display “GO” (flash) if all test steps in the
module pass, and will show “NG” (flash) if there is at least one failure during
the test.
• At that point, you can either press the Start key to continue with another test,
or press EXIT (State 2) key to quit the Auto-Sequence function.
M540070-01 Rev B 3-5
