Figure 4-2. potentiometer locations -5 – AMETEK SFA Series User Manual
Page 57
Sorensen SFA Series
Verification and Calibration
STANDARD CALIBRATION ADJUSTMENT
R71 = IPRES (1mA) Adjust
R87 = Voltage Meter Adjust
R86 = Current Meter Adjust
R69 = 100% Current Adjust
R55 = Zero Current Adjust
ISOLATED ANALOG (OPTION)
CALIBRATION ADJUSTMENT
R86 = Voltage Meter Adjust
R87 = Current Meter Adjust
R33 = 100% Current Adjust
R47 = Zero Current Adjust
FACTORY USE ONLY
R35 R73
R37 R74
R39 R82
R45 R85
R46 R90
R54
R104
Figure 4-2. Potentiometer Locations
M550292-01 Rev G
4-5
