Audio Input Signal
Shows information about audio input signals.
F Menu screen F
2.Audio Input Signal
3.HDMI Information
4.Auto Surround Mode
5.Quick Select
6.Preset Station
1.Status
5.Information
Dialogue normalization function
This is automatically activated when playing Dolby Digital sources.
This function automatically corrects the standard signal level for
individual program sources.
The correction value can be checked using the STATUS button on
the main unit.
The figure is the correction value when the standard level is
corrected.
[Items to be checked]
Surround Mode
: The currently set surround mode is displayed.
SIGNAL
: The input signal type is displayed.
fs
: The input signal’s sampling frequency is
displayed.
Format
: The number of channels in the input signal (front,
surround, LFE) is displayed.
Offset
: The dialogue normalization correction value is
displayed.
Flag
: “MATRIX” is displayed if the input signal has
undergone matrix processing, “DISCRETE” if the
input signal has undergone discrete processing.
HDMI Information
Shows information about HDMI input/output signals and monitor.
F Menu screen F
2.Audio Input Signal
3.HDMI Information
4.Auto Surround Mode
5.Quick Select
6.Preset Station
1.Status
5.Information
a HDMI Signal Information
The HDMI input/output signal information is displayed.
[Items to be checked]
Resolution Color Space Pixel Depth
s HDMI Monitor Information
The HDMI monitor information is displayed.
[Items to be checked]
Interface Support Resolution
Auto Surround Mode
Shows information about auto surround mode settings.
The surround mode for which the last memory function was used
for the different input signal types is displayed.
F Menu screen F
2.Audio Input Signal
3.HDMI Information
4.Auto Surround Mode
5.Quick Select
6.Preset Station
1.Status
5.Information
[Items to be checked]
Analog/PCM 2CH Multi ch Digital 2CH Digital 5.1CH
Quick Select
Shows information about quick select settings.
F Menu screen F
2.Audio Input Signal
3.HDMI Information
4.Auto Surround Mode
5.Quick Select
6.Preset Station
1.Status
5.Information
For instructions on storing settings at Quick Select 1 to 3, see page
50.
[Items to be checked]
Name Input Source Input Mode Volume Level
Analog/PCM 2CH Multi ch Digital 2CH Digital 5.1CH
Preset Station
Shows information about preset stations.
F Menu screen F
2.Audio Input Signal
3.HDMI Information
4.Auto Surround Mode
5.Quick Select
6.Preset Station
1.Status
5.Information
[Input source] TUNER XM
[Items to bechecked] A1 ~ G8
When the STATUS button on the main unit is pressed, the set’s status
can be checked on the display.
DOLBY DIGITAL EX
SIGNAL:Dolby Digital
fs :48kHz
Format:3/2/.1
Offset:-4dB
Surround Mode:
5-2.Audio Input Signal
480i
1080p
Color Space
YCbCr 4:2:2
YCbCr 4:4:4
Pixel Depth
8bits
10bits
Resolution
5-3.HDMI Signal Info.
5-4.Auto Surround Mode
[Analog][PCM]
2CH:STEREO
[Multi ch]
:MULTI CH IN
[Digital]
2CH:DOLBY PL IIx Cinema
5.1CH:DOLBY/DTS SURROUND
5-6.Preset Station
A1FM 87.50MHz
A2FM 89.10MHz
A3FM 98.10MHz
A4FM107.90MHz
A5FM 90.10MHz
A6FM 90.10MHz
A7FM 90.10MHz
A8FM 90.10MHz
5-5.Quick Select
1/2
1.Quick Select 1
2.Quick Select 2
3.Quick Select 3
