Zone Setup
Make settings for audio playback in a multi-zone system.
F Menu screen F
2.Manual Setup
2.HDMI Setup
1.Speaker Setup
4.Zone Setup
5.Option Setup
3.Audio Setup
a ZONE2 Setup
Make settings for audio playback in a ZONE2 system.
s ZONE3 Setup
Make settings for audio playback in a ZONE3 system.
Bass
Adjust low frequency range (bass).
[Variable range] –10dB ~ 0dB ~ +10dB
Treble
Adjust high frequency range (treble).
[Variable range] –10dB ~ 0dB ~ +10dB
HPF
When using speakers that cannot satisfactorily play low frequencies,
distortion of the bass sound can be reduced by setting “HPF” to
“ON”.
[Selectable items]
OFF
: The low range is not attenuated.
ON
: The low range is attenuated.
Lch Level
Adjust the left channel output level.
[Variable range] –12dB ~ 0dB ~ +12dB
Rch Level
Adjust the right channel output level.
[Variable range] –12dB ~ 0dB ~ +12dB
Channel
Switch between stereo and mono output.
[Selectable items]
Stereo
: Select stereo output.
Mono
: Select monaural output.
When menu “Manual Setup” – “Option Setup” – “Amp Assign”
(vpage 31) is set to ZONE2/3-MONO”, the “Channel” setting is
automatically set to “Mono”.
2.ZONE3 Setup
1.ZONE2 Setup
2-4.Zone Setup
Volume Limit
Make a setting for maximum volume.
[Selectable items]
OFF
: Do not set a maximum volume.
–20dB
: Set the maximum volume to –20 dB.
–10dB
: Set the maximum volume to –10 dB.
0dB
: Set the maximum volume to 0 dB.
Power On Level
Define the volume setting that is active when the power is turned on.
[Selectable items]
Last
: Use the memorized setting from the last session.
– – –
: Always use the muting on condition when power
is turned on.
–70dB ~ +18dB
: Set the volume level when the power is turned on
in units of 1 dB.
Mute Level
Set the amount of attenuation when muting is on.
[Selectable items]
Full
: The sound is cut off entirely.
–40dB
: The sound is attenuated by 40 dB.
–20dB
: The sound is attenuated by 20 dB.
Volume Level
Adjust the main volume level.
[Selectable items]
VAR
: Allow volume adjustment by remote control.
–40dB
: Fix the volume to –40 dB.
0dB
: Fix the volume to 0 dB.
“VAR” is displayed when a power amplifier is assigned to the ZONE2
output channel at menu “Manual Setup” – “Option Setup” – “Amp
Assign” (vpage 31).
