Decoder User Manual
Manual-MPEG4_DECA-Rev1206
Copyright © KBC Networks 2011
Page 5 of 29 www.kbcnetworks.com
Software OS Supported Win 2000, XP, 2003, Vista, 7
Security Username / password
Mechanical
Physical Metal housing, not weatherproof
Dimensions (L x W x H)
40 x 120 x 136 mm
(1.56 x 4.72 x 5.37 in)
Weight
0.37 kg
(12.9 oz)
Certification CE, FCC Class B
Power
Power Requirements 12 Vdc @ 625mA, 7.5W
Power Supply
12 Vdc 1500mA, wall transformer
supplied
Environmental
Humidity 10% ~ 90%
Operating Temperature
-30° ~ +70 °C
(-22° ~ +158 °F)
Connectors
10/100 Electrical 1 x RJ45
Composite 1 x BNC; 1 x Y/C
RS-422/485/232
4 ports of 6 pin terminal block (2 ports
for voltage in)
DI/DO 6 pin terminal block
Power 2 ports of RS Data 6 pin terminal block
Approvals
FCC Part 15 subpart C
IC ID# 7849A-N523ESD
CE Class A
