Input Monitoring menu
Check Ok Input Monitoring
Input A off
Input B off
Mode Analog Pilot
Input Monitoring Input A
Back
Mode
on
...
D12 Stage right
Q7
-3.0dB -3.0dB
CUT HFA EQ 0.01 CSA EQ
Q-SUB
+0.0dB D
P P
100
Mode
Selecting "Mode" and pressing the encoder allows the setting of the
following functions:
Analog Pilot: monitor incoming pilot signal at the analog inputs
Digital Pilot:
monitor incoming pilot signal at the digital input
Digital Lock: monitor whether the digital input has locked
Input A / Input B
Selecting either "Input A" or "Input B" and pressing the encoder allows
the following settings for each channel independently.
Mode
Selecting "Mode" in the "Input A or B" submenu and pressing the
encoder activates "Input Monitoring" (indicated as "
P " in the main
screen). An error message will be generated if no signal is detected.
Detection Time 1s
Detection Time 99s
Fig. 8: D12 Input Monitoring, Detection
Time
Detection Time
The maximum time interval an interruption of the monitored pilot signal
or digital clock is accepted without generating an error message.
Detection Time 99s Notch Filter on
D12 Stage right
J12
-3.0dB -3.0dB
HFC LFC EQ 0.01
Active
0.3ms D
P L
CAN C -5
n
Notch on/off
A notch filter is available to remove the pilot signal from the program
signal. However, if activated, the Notch filter remains active even if the
Input Monitoring is set to off (Mode off). The on/off status of the Notch
filter is indicated by "
n " in the main screen as shown in the graphic
opposite - Fig. 8.
Frequency
Center frequency of the notch filter adjustable from 1 Hz to 20 kHz in
1 Hz steps.
Frequency 1Hz
Frequency 20000Hz
Freq. Fine +0.99Hz
Freq. Fine - 0.99Hz
Quality 4
Quality 42
Freq. Fine
Fine tuning of the center frequency ± 1 Hz, 1/100 Hz steps.
Quality
The Q of the filter is adjustable from 4 ... 42 in 1 detent steps. The
center frequency is fully attenuated (⇒ –∞
dB).
Detected? no (yes)
The signal level in dBu detected at the set pilot frequency is displayed
on the right hand side. "Detected?" is followed by the message ("yes" or
"no") depending on the threshold level (see "Threshold" below).
Detected? no - 94dBu
Threshold - 42dBu
Detected? yes - 42dBu
Threshold - 42dBu
Threshold
Detection threshold for an external Pilot Signal of the set frequency,
adjustable in a range of –122 dBu to +21 dBu in 1 dB steps.
