7.12. ANALOG
Analog output provides analog output 0 - 10 V. When connecting with another device (e.g. dimmer) it is
essential to see to a perfect interconnection with earth. The output voltages generated by the analog output is
mutually related to the reference level (ground) on pin labeled G.
Analog output is applicable as follows
•
ANALOG 1 - 4 for ipCUE-delta and ipCUE-epsilon.
Nor applicable for ipCUE-alpha, ipCUE-beta, ipCUE-gamma, ipCUE-sigma.
Parameters of the analog output
•
Range of the output voltage
0 - 10 V
•
Max. output current (both source and sink)
10 mA
•
Stepping regulation (LSB)
39 mV
•
Min. set-up precision
± 0.08 V (± 2 LSB)
Connector pin out
Note: All pins labeled G are connected together.
User Manual ipCUE Controllers
Page 27 of 52
ANALOG
Pin
S
Description
Analog Output Signal 0 – 10 V
2-pin 3.5 mm
G
Ground
S
G
