Name Required Description
parallelterminationcontrol_b
No Receives the current state of the pull up and pull
down
Rt
control buses from a termination logic
block. Input port
[((WIDTH_PTC * NUMBER_OF_
CHANNELS) - 1)..0]
wide. Port is applicable only
when the
USE_TERMINATION_CONTROL
parameter
value is
TRUE
.
Table 13: ALTIOBUF (As Bidirectional Buffer) Output Ports
This table lists the output ports for ALTIOBUF IP core (as bidirectional buffer)
Name Required Description
dataout[]
Yes Buffer output port. Output port
[NUMBER_OF_
CHANNELS - 1..0]
wide. The I/O output buffer
element output.
Table 14: ALTIOBUF (As Bidirectional Buffer) Bidirectional Ports
This table lists the bidirectional ports for ALTIOBUF IP core (as bidirectional buffer)
Name Required Description
dataio[]
Yes Bidirectional port that directly feeds a bidirectional
pin in the top-level design. Bidirectional port
[(NUMBER_OF_CHANNELS - 1)..0]
wide.
dataio_b[]
No Bidirectional DDR port that directly feeds a bidirec‐
tional pin in the top-level design. Bidirectional port
[(NUMBER_OF_CHANNELS - 1)..0]
wide. The
negative signal input/output to/from the I/O buffer.
This port is used only if the
use_differential_
mode_parameter
is set to
TRUE.
Table 15: ALTIOBUF (As Bidirectional Buffer) Parameter
This table lists the parameters for ALTIOBUF IP core (as bidirectional buffer)
Name Required Type Description
ENABLE_BUS_HOLD
No String Specifies whether the bus hold circuitry is
enabled. Values are
TRUE
and
FALSE
.
When set to
TRUE
, bus hold circuitry is
enabled, and the previous value, instead of
high impedance, is assigned to the output
port when there is no valid input. If
omitted, the default is
FALSE.
Currently,
ENABLE_BUS_HOLD
and
USE_
DIFFERENTIAL_MODE
cannot be used
simultaneously.
26 ALTIOBUF Signals and Parameters: As Bidirectional Buffer
UG-01024
2014.12.15
