Name
Required
Description
dynamicterminationcontrol[]
No
Input signal for bidirectional I/Os. Input port
[NUMBER_OF_CHANNELS - 1..0]
wide. When
specified, this port selects from the core either
Rs
code, when the input value is
LOW
; or
Rt
code, when
the input value is
HIGH
. Enable
Rt
only when the
bidirectional I/O is receiving input. When the
bidirectional I/O is not receiving input, disable this
port for optimal output performance and power
dissipation.
Value
Rs Code
Rt Code
0
1
0
1
0
1
dynamicterminationcontrol_b
No
Input signal for bidirectional I/Os. Input port
[NUMBER_OF_CHANNELS - 1..0]
wide. When
specified, this port selects from the core either
Rs
code, when the input value is
LOW
; or
Rt
code, when
the input value is
HIGH
. Enable
Rt
only when the
bidirectional I/O is receiving input. When the
bidirectional I/O is not receiving input, disable this
port for optimal output performance and power
dissipation. Port is available only when the
USE_
DIFFERENTIAL_MODE
parameter value is
TRUE
.
Value
Rs Code
Rt Code
0
1
0
1
0
1
seriesterminationcontrol[]
No
Receives the current state of the pull up and pull
down
Rs
control buses from a termination logic
block.
[WIDTH_STC * NUMBER_OF_CHANNELS -
1..0]
wide. Port is applicable only when the
USE_
TERMINATION_CONTROL
parameter value is
TRUE
.
seriesterminationcontrol_b
No
Receives the current state of the pull up and pull
down
Rs
control buses from a termination logic
block.
[WIDTH_STC * NUMBER_OF_CHANNELS -
1..0]
wide. Port is applicable only when the
USE_
TERMINATION_CONTROL
parameter value is
TRUE
.
parallelterminationcontrol[]
No
Receives the current state of the pull up and pull
down Rt control buses from a termination logic
block. Input port
[((WIDTH_PTC * NUMBER_OF_
CHANNELS) - 1)..0]
wide. Port is applicable only
when the
USE_TERMINATION_CONTROL
parameter
value is
TRUE
.
