Altera Corporation 4–5
October 2006 Cyclone II FPGA Starter Development Kit User Guide
Using the Control Panel
Figure 4–4. Control Panel SDRAM Tab Window
2. To write a 16-bit word into the SDRAM, use the Random Access
boxes to enter the address of the desired location, specify the data to
write, and click on the Write button.
3. To read the contents of a location, enter the address and click on the
Read
button.
Sequential Write
To write the contents of a file into the SDRAM, use the Sequential Write
function of the Control Panel to perform the following steps:
1. Select the SDRAM tab on the Control Panel and use the Sequential
Write
boxes.
2. Specify the starting address in the Address box.
3. Specify the number of bytes to write in the Length box. To load the
entire file, only checkmark the File Length box without specifying
the number of bytes.
