4.2 Configuration
4 Function description
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]
4-4
4.2 Configuration 4200 Configuration 4- ][Funktionsbeschreibung_BA_Konfig Keine Konfig
The module does not have to be configured.
4.2.1 Addresses in the process image
Addresses in the process image 4- ][Funktionsbeschreibung_BA_PA Keine Adresse
The module does not occupy any addresses in the process image.
4.2.2 FS error behaviour
FS error behaviour 4- ][Funktionsbeschreibung_BA FS-Fehler
In the case of a safety-related error on an FS output, all FS outputs in the
affected I/O-Group (SafetyBUS p) are shut down.
In the case of a safety-related error on an FS input, the process image
of all FS inputs in the affected I/O-Group (SafetyBUS p) is set to zero.
The I/O-Group switches to a STOP condition. An error telegram is then
triggered on SafetyBUS p and the error is entered in the PSSuniversal
error stack.
