7.2 Display elements
7 Operation
Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany
Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: [email protected]
7-2
7.2 Display elements 7200 Display elements 7- Anzeige Legende 3x
Key:
7.2.1 Display elements for device diagnostics
Display elements for device diagnostics 7- Betrieb_Anzeige_Verbindungsmodul ml2p_BA
LED on
LED flashes
LED off
LED LED status Meaning
READY Green The unit is ready for operation
The unit is not ready for operation
FAULT Red External error
Red Internal error
No error
TR Yel-
low Connection to a decentralised module available
Yel-
low Connection is not available to all decentralised modules.
No connection to a decentralised module
