Accessories
A-2
Falcon
®
4400 Series with Windows
®
CE
Power Supplies
Battery Pack
Figure A-1. 4-Battery Pack
Single-Slot Dock
Figure A-2
.
Single Slot Dock
Use only the correct battery chargers and docks with this Windows CE color Fal-
con. This technology used for these models is incompatible with other Datalogic
Mobile Falcon chargers and docks.
Power LED
USB/Serial Connector
Spare Battery
LED
Battery Pack in
Spare Battery
Charging Slot
