Parts list – Vortech 2003-2004 Mustang Mach 1 User Manual
Page 7
P/N: 4FR020-010
©2004 Vortech Engineering, LLC
All Rights Reserved, Intl. Copr. Secured
23AUG04 86-93 4V Mus. Cobra(4FR v3.1)
P/N: 4FR020-010
©2004 Vortech Engineering, LLC
All Rights Reserved, Intl. Copr. Secured
23AUG04 86-93 4V Mus. Cobra(4FR v3.1)
Part Number Description Quantity
2E229-170 V-2 SC-TRIM SUPERCHARGER ASSEMBLY 1
4FR111-021 '99 MOUNTING BRACKET ASSEMBLY 1
7A375-178 3/8-16 x 1-3/4” HXHD G8 3
7K375-040 3/8” AN960 Flat Washers 5
7K312-001 5/16" AN Washers 9
2A046-113 Belt, K061130-Gates 4.6 4V 1
4FK011-031 Mounting Bracket 1
7J312-875 5/16" Custom Washer 1
7C080-065 8mm x 1.25 x 65 SOC 1
4FK116-021 Idler Pulley Assembly 1
2A017-025 Spacer, Idler 4V 1
7C080-016 8mm x 1.25 x 16 HXHD Bolt 1
7C080-140 8mm x 1.25 x 140 HXHD Bolts 2
7C080-070 8mm x 1.25 x 70 HXHD Bolts 2
7U313-133 M8 x 1.25" 4V Alternator Stud 1
7F008-020 M8 x 1.25 Nut 1
7A375-225 3/8-16 x 2-1/4" HXHD G8 2
7J010-001 #10 Flat Washers 4
7C080-025 8mm x 1.25 x 25 HXHD 2
7C010-050 10-24 x 1/2" SOC HD CAP, ZINC PLT 4
4FK016-081 Water Pump Pulley, Stock 1
4FR010-011 Plaque, '99 4V Mtng Brkt. 1
4FR112-015 AIR INTAKE ASSY, '01 4V 1
4FR012-010 Inlet Elbow, Mod Cast 4V 1
4FR110-050 90mm MAF Brkt Assy 1
7R002-056 #56 Goldseal Hose Clamp 2
7S350-200 3-1/2 x 2 Sleeve 1
7U035-001 3-1/2" Flex Hose 1
7R002-052 #52 Goldseal Hose Clamp 2
8H040-097 Air Filter, 4" Flg 7" Long 1
7A250-075 1/4-20 x 3/4 SHCS Plated 4
7F250-021 1/4-20 Nylock Nut zinc Plated 4
7U100-052 7/16 Rubber Grommet 1
7U100-056 Vent Tube 90° 1
7R001-008 #8 Stnls Hose Clamp 1
7U100-055 Tie Wrap, 6" Nylon 10
7J250-001 1/4 SAE Washer, Plated 4
7U038-000 3/4" Heater Hose 1
4FK012-040 Air Inlet Elbow 4.6 GEN2 1
7P750-100 3/4 NPT x 1" Hose Fitting 1
7R002-064 #64 Goldseal Hose Clamp 2
7S400-200 4 x 2 Sleeve 1
8A003-040 MAF, 90mm 1
7U375-055 Vacuum Cap, 5/8" Nipple 1
7E010-049 #10 x 3/4 Hex Head Sheet 2
4PFL010-041 Brkt, Fan Resistor Reloc 1
7C010-075 10-24 x 3/4 SHCS GR5 Zinc 2
7F010-024 10-24 Nylock Nut 2
4FR114-010 COOLANT PIPE ASSEMBLY '99+ 1
7U100-046 O-Rings 2
4FE014-010 Radiator Pipe Stnlss 1
7U133-050 1-1/2" x 90° Hose 1
7R002-020 #20 Goldseal Hose Clamps 3
7R002-024 #24 Goldseal Hose Clamps 3
7P375-016 3/8" Pipe Plug 1
70000 Inspector Number 0
4FR014-010 '99 U-Bend Assembly-Coated 1
4FR014-020 '99 L-Bend Assembly-Coated 1
7F006-093 6mm Nylock Nuts 2
4FH130-036 OIL DRAIN ASSEMBLY 1
(See Parts List For 4FR218-010SQ)
4FH130-026 OIL FEED ASSEMBLY 1
(See Parts List For 4FR218-010SQ)
1999 4.6L DOHC Mustang w/aftercooler
Part No. 4FR218-020SQ
PARTS LIST
Part Number Description Quantity
4FR112-030 DISCHARGE ASSEMBLY '99 4V COOLER 1
7R002-044 #44 Goldseal Hose Clamps 2
7R002-016 #16 Goldseal Hose Clamps 4
8D001-001 Bypass Valve 1
7U034-016 1" GS Hose 0.229'
7U034-016 1" GS Hose 0.312'
7U030-046 5/32" Vacuum Line 4'
7P156-082 5/32" TEE 1
7S450-200 4-1/2" x 2" Sleeve 1
7R002-072 #72 Goldseal Hose Clamps 2
7S275-300 2-3/4" x 3" Sleeve 1
4FR012-030 Duct Discharge B 1
7R002-056 #56 Goldseal Hose Clamp 1
7P500-078 1/2" NPT x 3/4" HOSE Fits 2
7R002-048 #48 Goldseal Hose Clamps 2
7S350-301 Reducer, 3-1/2" to 3" 1
8N101-060 Welded Core Assembly 1
008341 Powercooler Decal 1
8N106-030 WATER COOLER ASSEMBLY, 4.6 1
7A250-075 1/4-20 X 3/4 SHCS PLTD 4
7F250-021 1/4-20 Nylock Nuts 4
7J250-001 1/4 SAE Washers 8
7P500-026 1/2 NPT-3/4 Barbs 90° 2
8N006-010 Water Cooler 1
7E010-075 #12 x 3/4" Sheet Metal Screw 4
7J010-001 #10 Flat Washers 4
8N010-050 Mount Tabs, Cooler 2
8N107-020 WATER PUMP ASSEMBLY, 4.6 1
5W001-011 16-14 GA Eyelet .25" Hole 1
5W001-012 Solderless Connector 1
5W018-010 18GA Strd Wire Red 8-1/4'
5W001-019 Solderless Connectors 10-12 2
5W001-014 Fuse Holder 10 GA Wire 1
5W001-015 Fuse, Blade Type 20 amp 1
5W001-015 12-10 GA Female Slide 1
5W001-002 Fuse Tap 1
8N010-060 Bracket, Bosch Water Pump 1
8F001-403 Pump, Water Bosch 1
5W001-050 Connector, Fuel Injector 1
7E010-075 #12 x 3/4" Sheet Metal Screws 2
7J010-001 #10 Flat Washers 2
7U133-060 3/4" x 90° Hose Elbow 1
5W001-024 Mini ATC Fuse Tap 1
5w001-025 Female Slide, Insulated Mini 1
8N105-030 WATER TANK ASSEMBLY, 4.6 1
7U038-000 3/4" Heater Hose 20
7R007-001 Nylon Clamps 1-1/8" 8
7R003-016 Adel Clamps, 7/8" 3
7E010-075 #12 x 3/4" Sheet Metal Screws 3
7J010-001 #10 Flat Washers 3
7U100-044 Tie Wraps, 4" Nylon 16
7U100-066 Tie Wraps, 11" Nylon 6
8N105-010 Water Tank w/Fitting 1
8N201-060 PWR COOLR ASSY '99 4.6 4V 1
8N101-060 Welded Core Assy '99 4.6 4V 1
7R002-048 #48 Goldseal Hose Clamp 1
7P500-078 1/2NPT x 3/4 Hose Fit 2
7S350-301 Reducer, 3.50-3.00 1
008341 PowerCooler Decal 1
4FL120-025 ECM PCK/SHPNG ASSEMBLY '99 4V 1
8F060-042 FUEL INJECTOR 42LB 8
5W001-051 JUMPER HARNESS 8
8F101-260 FUEL PUMP 1
vii
®
ENGINEERING, LLC
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any shortages or dam-
aged parts immediately.
