Parts list – Vortech 2003-2004 Mustang Mach 1 User Manual

Page 6

P/N: 4FR020-010

23AUG04 86-93 4V Mus. Cobra(4FR v3.1)

P/N: 4FR020-010

23AUG04 86-93 4V Mus. Cobra(4FR v3.1)

Part Number Description Quantity

2E229-160 V-2 E-TRIM SUPERCHARGER ASSEMBLY 1
4FR111-021 '99 MOUNTING BRACKET ASSEMBLY 1

7A375-178 3/8-16 x 1-3/4” HXHD G8 3

7K375-040 3/8” AN960 Flat Washers 5

7K312-001 5/16" AN Washers 9

2A046-113 Belt, K061130-Gates 4.6 4V 1

4FK011-031 Mounting Bracket 1

7J312-875 5/16" Custom Washer 1

7C080-065 8mm x 1.25 x 65 SOC 1

4FK116-021 Idler Pulley Assembly 1

2A017-025 Spacer, Idler 4V 1

7C080-016 8mm x 1.25 x 16 HXHD Bolt 1

7C080-140 8mm x 1.25 x 140 HXHD Bolts 2

7C080-070 8mm x 1.25 x 70 HXHD Bolts 2

7U313-133 M8 x 1.25" 4V Alternator Stud 1

7F008-020 M8 x 1.25 Nut 1

7A375-225 3/8-16 x 2-1/4" HXHD G8 2

7J010-001 #10 Flat Washers 4

7C080-025 8mm x 1.25 x 25 HXHD 2

7C010-050 10-24 x 1/2" SOC HD CAP, ZINC PLT 4

4FK016-081 Water Pump Pulley, Stock 1

4FR010-011 Plaque, '99 4V Mtng Brkt. 1

4FR112-015 AIR INTAKE ASSY, '01 4V 1

4FR012-010 Inlet Elbow, Mod Cast 4V 1

4FR110-050 90mm MAF Brkt Assy 1

7R002-056 #56 Goldseal Hose Clamp 2

7S350-200 3-1/2 x 2 Sleeve 1

7U035-001 3-1/2" Flex Hose 1

7R002-052 #52 Goldseal Hose Clamp 2

8H040-097 Air filter, 4" Flg 7" Long 1

7A250-075 1/4-20 x 3/4 SHCS Plated 4

7F250-021 1/4-20 Nylock Nut Zinc Plated 4

7U100-052 7/16 Rubber Grommet 1

7U100-056 Vent Tube 90° 1

7R001-008 #8 Stnls Hose Clamp 1

7U100-055 Tie Wrap, 6" Nylon 10

7J250-001 1/4 SAE Washer, Plated 4

7U038-000 3/4" Heater Hose 1

4FK012-040 Air Inlet Elbow 4.6 GEN2 1

7P750-100 3/4 NPT x 1" Hose Fitting 1

7R002-064 #64 Goldseal Hose Clamp 2

7S400-200 4 x 2 Sleeve 1

8A003-040 MAF, 90mm 1

7U375-055 Vacuum Cap, 5/8" Nipple 1

7E010-049 #10 x 3/4 Hex Head Sheet 2

4PFL010-041 Brkt, Tan Resistor Reloc 1

7C010-075 10-24 x 3/4 SHCS GR5 Zinc 2

7F010-024 10-24 Nylock Nut 2

4FR114-010 COOLANT PIPE ASSEMBLY '99+ 1

7U100-046 O-Rings 2

4FE014-010 Radiator Pipe Stnlss 1

7U133-050 1-1/2" x 90° Hose 1

7R002-020 #20 Goldseal Hose Clamps 3

7R002-024 #24 Goldseal Hose Clamps 3

7P375-016 3/8" Pipe Plug 1

70000 Inspector Number 0

4FR014-010 '99 U-Bend Assembly-Coated 1

4FR014-020 '99 L-Bend Assembly-Coated 1

7F006-093 6mm Nylock Nuts 2

4FH130-036 OIL DRAIN ASSEMBLY 1

7U030-036 1/2” x 14” Oil Drain Hose 1

7R001-008 #8 Stainless Hose Clamps 2

7P500-003 90° 1/2" Alum. Tube 1

7P500-020 Tube Nut 1

7P375-042 Male Connector 1

1999 4.6L DOHC Mustang

Part No. 4FR218-010SQ

PARTS LIST

Part Number Description Quantity

4FH130-026 OIL FEED ASSEMBLY 1

7U030-026 1/4” x 26” Oil Feed Hose 1

7P525-067 .525 Crimp Ferrules 2

7P250-066 #4 Swivel x 1/4” Hose Barb Fitting 2

7P125-103 1/8” NPT -4 x 45° Male Elbow 1

7P250-082 1/4" NPT x -4 90° Fitting 1

7P250-034 1/4 NPT Street TEE 1

7P250-036 -4 Flare to 1/4 NPT 1

4FR112-015 DISCHARGE ASSEMBLY 1

7S275-300 2-3/4" x 3" Sleeve 1

7R002-044 #44 Goldseal Hose Clamps 2

7R002-016 #16 Hose Goldseal Clamps 4

8D001-001 Bypass Valve 1

7U034-016 1" GS Hose 1

7U030-046 5/32" Vacuum Line 1

7P156-082 5/32" TEE 1

7S450-200 4-1/2" x 2" Sleeve 1

7R002-072 #72 Goldseal Hose Clamps 2

7P750-100 3/4" NPT x 1" Hose Fitting 1

4FR012-030 Duct Discharge B '99 Cobra 1

7S350-200 3-1/2" x 2" Sleeve 1

7R002-056 #56 Goldseal Hose Clamps 2

4FR012-020 Duct Discharge A - Casting 1

4FR020-020 ECM CHIP PKG/SHPNG ASSY 99 1

8F060-042 FUEL INJECTOR 42LB 8
5W001-051 JUMPER HARNESS 8
8F101-260 FUEL PUMP 1

ENGINEERING, LLC

IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any shortages or dam-

aged parts immediately.

This manual is related to the following products:

1999 & 2001 Ford 4.6L Mustang Cobra
