Parts list – Vortech 2003-2004 Mustang Mach 1 User Manual

Page 10

P/N: 4FR020-010

23AUG04 86-93 4V Mus. Cobra(4FR v3.1)

P/N: 4FR020-010

23AUG04 86-93 4V Mus. Cobra(4FR v3.1)

2003-2004 4.6L DOHC Mach 1 Mustang

Part No. 4FR218-080SQ

PARTS LIST

Part Number Description Quantity

4FR114-012 COOLANT PIPE ASSY '99+ 1

7U100-046 O-Rings 2

4FE014-010 Radiator Pipe Stnlss 1

7U133-050 1-1/2" x 90° Hose 1

7R002-020 #20 Goldseal Hose Clamps 3

7R002-024 #24 Goldseal Hose Clamps 3

7P375-016 3/8" Pipe Plug 1

70000 Inspector Number 0

4FR014-010 '99 U-Bend Assembly-Coated 1

4FR014-020 '99 L-Bend Assembly-Coated 1

7F006-093 6mm Nylock Nuts 2

7P500-020 Tube Nut 1

7P375-042 Male Connector 1

4FH130-036 OIL DRAIN ASSEMBLY 1

7U030-036 1/2” x 14” Oil Drain Hose 1

7R001-008 #8 Stainless Hose Clamps 2

7P500-003 90° 1/2" Alum. Tube 1

4FH130-026 OIL FEED ASSEMBLY 1

7U030-026 1/4” x 26” Oil Feed Hose 1

7P525-067 .525 Crimp Ferrules 2

7P250-066 #4 Swivel x 1/4” Hose Barb Fitting 2

7P125-103 1/8” NPT -4 x 45° Male Elbow 1

7P250-082 1/4" NPT x -4 90° Fitting 1

7P250-034 1/4 NPT Street TEE 1

7P250-036 -4 Flare to 1/4 NPT 1

4FR112-020 DISCHARGE ASSEMBLY 1

7S275-300 2-3/4" x 3" Sleeve 1

7R002-044 #44 Goldseal Hose Clamps 2

7R002-016 #16 Hose Goldseal Clamps 4

8D001-001 Bypass Valve 1

7U034-016 1" GS Hose 1

7U030-046 5/32" Vacuum Line 1

7P156-082 5/32" TEE 1

7S450-200 4-1/2" x 2" Sleeve 1

7R002-072 #72 Goldseal Hose Clamps 2

7P750-100 3/4" NPT x 1" Hose Fitting 1

4FR012-030 Duct Discharge B '99 Cobra 1

7S350-200 3-1/2" x 2" Sleeve 1

7R002-056 #56 Goldseal Hose Clamps 2

4FR012-020 Duct Discharge A - Casting 1

2E229-190 V2SQ SC-TRIM ASY, 03 MACH 1 STD 1

2A036-361 S/C Pulley 3.60" 6-Grv 1

4FL120-025 ECM CHIP PKG/SHPNG ASSY '01 1

5W001-051 JUMPER HARNESS 8
8F101-265 FUEL PUMP 1
8F060-042 FUEL INJECTOR 42 lb. 8
2A046-112 BELT, 6-RIB GATES K061120 1

ENGINEERING, LLC

IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any shortages or dam-

aged parts immediately.

Part Number Description Quantity

4FR111-041 '03 MACH 1 MNTG BRACKET ASSEMBLY 1

7A375-178 3/8-16 x 1-3/4 HXHD G8 3

7K375-040 3/8 AN960 Flat Washer Plated 6

7K312-001 5/16 AN-Washer 14

4FR011-021 Mach. Mtg Bkt, '01 4V 1

7J312-875 5/16" Washer, Custom 1

7C080-065 8mm x 1.25 x 65 SOC 1

7C080-016 8mm x 1.25 x 16 HXHD 2

7C080-140 8mm x 1.25 x 140 HXHD 2

7C080-070 8mm x 1.25 x 70mm HXHD Zinc 1

7U313-133 M8 x 1.25 Stud, 4V Alternator 1

7F008-020 M8 x 1.25 Nut 1

7A375-225 3/8-16 x 2-1/4 HXHD G8 2

7J010-001 #10 Flat Washer 4

7C080-025 8mm x 1.25 x 25 HXHD 2

7C010-052 10-24 x 1/2 Button Hd. Cap 4

4FR010-011 Plaque, '99 4V Mtng Brkt 1

7C060-075 M6 x 1.0 x 75 HXHD Zink Plated 2

7A375-100 3/8-16 x 1 G5 HXHD Plated 1

7A312-175 5/16-18 x 1-3/4 HXHD G5 Zinc Plated 2

7A312-100 5/16-18 X 1 HXHD GR5P 1

7C080-130 M8 x 1.25 x 130 HXHD Zinc Plated 1

2A017-016 Shrt. Assy. Idler, V-3 1

4FR017-021 Spacer. Alternator '01 4V 2

4FR017-041 Alt Brkt, D-Side '01 4V 1

4FR017-051 Alt Brkt, P-Side, '01 4V 1

4FR111-032 Assy, Idler Plate, '01 4V 1

7J006-093 6mm Washer, Plated 2

2A046-115 Belt, K061115-Gates Vortec 1

4FH016-150 Idler Pulley, 6Rib 3" Flanged 1

4FR017-031 Spacer, Alt/Mtg Brkt, '01 4V 1

4FR112-017 AIR INTAKE ASSY, '03 MACH 1 1

4FR012-010 Inlet Elbow, Mod Cast 4V 1

4FR110-050 90mm MAF Brkt Assy 1

7R002-056 #56 Goldseal Hose Clamp 2

7S350-200 3-1/2 x 2 Sleeve 1

7U035-001 3-1/2" Flex Hose 1

7R002-052 #52 Goldseal Hose Clamp 2

8H040-097 Air Filter, 4" Flg 7" Long 1

7A250-075 1/4-20 x 3/4 SHCS Plated 4

7F250-021 1/4-20 Nylock Nut Zinc Plated 4

7U100-052 7/16 Rubber Grommet 1

7U100-056 Vent Tube 90° 1

7R001-008 #8 Stnls Hose Clamp 1

7U100-055 Tie Wrap, 6" Nylon 10

7J250-001 1/4 SAE Washer, Plated 4

7U038-000 3/4" Heater Hose 1

4FK012-040 Air Inlet Elbow 4.6 GEN2 1

7P750-100 3/4 NPT x 1" Hose Fitting 1

7R002-064 #64 Goldseal Hose Clamp 2

7S400-200 4 x 2 Sleeve 1

8A003-040 MAF, 90mm 1

7U375-055 Vacuum Cap, 5/8" Nipple 1

7E010-049 #10 x 3/4 Hex Head Sheet 2

4PFL010-041 Brkt, Fan Resistor Reloc 1

7C010-075 10-24 x 3/4 SHCS GR5 Zinc 2

7F010-024 10-24 Nylock Nut 2

5A002-014 Sensor, Ford Intake Air Temp 1

5W001-063 Harness, Ford IAT Sensor 1

4FR014-050 PCV Tube, 03 Mach 1 1

7P375-106 PCV Valve, Ford, 3/8" Hose 1

7P625-375 Reducer, 5/8" Barb to 3/8" Barb 1

7U032-016 3/8" EFI Fuel Hose Hi-Pressure .1666'

7U033-010R Hose, 5/8" ID Fuel, P/Str Ret 2"

7R001-006 #6 Stnls Hose Clamp, Carrow 2

7J250-001 1/4" Washer, SAE, Pltd 6

7A250-074 1/4"-20 x .75" HHCS Pltd 3

7F250-021 1/4"-20 Nylock Nut Zinc Pltd 3

4FR010-030 Shaker Bracket, P.Side 03 Mach 1 1

4FR010-040 Shaker Bracket, D.Side 03 Mach 1 1

4FR010-040R Shaker Bracket, D.Side 03 Mach 1,L 1
