Quantum Series 140 EHC 204 00sc 140 EHC 208 00sc
24
Module Addressing
The module uses sixteen zoom (parameter) registers, nine 4X (output) registers for configuration words, and
eight 3X (input) registers for data and status words.
Table 3-1 Module Registers
Register
Function
Zoom+0..7 Basic Configuration data (4ch - 0..3 / 8ch - 0..7)
Zoom+8**** Bank Switch Period in Autosequence Mode
4X Module Configuration Word
4X+1 Scale Factor / Count Limit Word
4X+2 Channel 1 Control Word
4X+3 Channel 2 Control Word
4X+4 Channel 3 Control Word
4X+5 Channel 4 Control Word
4X+6* Channel 5 Control Word
4X+7* Channel 6 Control Word
4X+8* Channel 7 Control Word
4X+9* Channel 8 Control Word
3X Module Status
3X+1*** Count Data LSW Chan 2*N-1
3X+2*** Count Data MSW 2*N-1
3X+3*** Count Data LSW Chan 2*N
3X+4*** Count Data MSW 2*N
3X+5*** Rate Data 2*N-1
3X+6*** Rate Data 2*N
3X+7*** Status Data 2*N-1
3X+8*** Status Data 2*N
Note X=bank number
*These registers only apply to the 8 channel counter (140 EHC 208 00).
***Comprehensive Mode shown. Speed mode explained in Data retrieval and Module Configuration Word (4X+0
Register under the description for Multiplexing Mode and Bank Number.
****The default is that the module update as fast as possible. This register allows the user to set in milliseconds the
update rate. For example, a 60 in this register will cause each bank to be updated in 60miliseconds. Since there are
four banks (in the 8 channel module) the total update time will be 240ms. In the four channel module the update
time would be 120ms.
