Quantum Series 140 MPM 204 00sc
26
Module Addressing Module Addressing Module Addressing Module Addressing Module Addressing
The module uses nine zoom (parameter) registers, six 4X (output) registers for configuration words, and eleven
3X (input) registers for data and status words.
T T T T Table 3-1 Module Registers able 3-1 Module Registers able 3-1 Module Registers able 3-1 Module Registers able 3-1 Module Registers
Register Function
Zoom+0..3 Basic Configuration data
Zoom+4 Autocycle time delay in milliseconds
Zoom+5 Channel 1 frequency reading timeout period in seconds. Max timeout =240 seconds.
Zoom+6 Channel 2 frequency reading timeout period in seconds. Max timeout =240 seconds.
Zoom+7 Channel 3 frequency reading timeout period in seconds. Max timeout =240 seconds.
Zoom+8 Channel 4 frequency reading timeout period in seconds. Max timeout =240 seconds.
4X Module Configuration Word
4X+1 Scale Factor / Count Limit Word
4X+2 Channel 1 Control Word
4X+3 Channel 2 Control Word
4X+4 Channel 3 Control Word
4X+5 Channel 4 Control Word
Bank 0 Bank 1 Bank 2 Bank 3
3X Module Status Module Status Module Status Module Status
3X+1 Count Data LSW Ch 1 Count Data LSW Ch 3 Met Proving LSW Ch 1 Met Proving LSW Ch 1
3X+2 Count Data MSW Ch 1 Count Data MSW Ch 3 Met Proving MSW Ch 1 Met Proving MSW Ch 1
3X+3 Count Data LSW Ch 2 Count Data LSW Ch 4 Met Proving LSW Ch 2 Met Proving LSW Ch 2
3X+4 Count Data MSW Ch 2 Count Data MSW Ch 4 Met Proving MSW Ch 2 Met Proving MSW Ch 2
3X+5 Rate Data LSW Ch 1 Rate Data LSW Ch 3 Met Proving LSW Ch 3 Met Proving LSW Ch 3
3X+6 Rate Data MSW Ch 1 Rate Data MSW Ch 3 Met Proving MSW Ch 4 Met Proving MSW Ch 3
3X+7 Rate Data LSW Ch 2 Rate Data LSW Ch 4 Met Proving LSW Ch 4 Met Proving LSW Ch 4
3X+8 Rate Data MSW Ch 2 Rate Data MSW Ch 4 Met Proving MSW Ch 4 Met Proving MSW Ch 4
3X+9 Status Data Ch 1 Status Data Ch 3 Met Proving Status Met Proving Status
3X+10 Status Data Ch 2 Status Data Ch 4 CM Error Count CM Error Count
Setting Up the Configuration Software Setting Up the Configuration Software Setting Up the Configuration Software Setting Up the Configuration Software Setting Up the Configuration Software
The module is compatible with several configuration software packages: ModSoft version 2.4 or later, Concept
version 2.1 or later, and ProWorx NxT. Setup and configuration instructions for ModSoft and Concept are
provided in this manual.
Included with the module is a 3.5-inch floppy disk. Install the disk files to update the configuration software so
that you can properly configure your module. These files update the configuration software and include
