FSI Monitor Software LUT Load
When CalMAN completes its automatic 3D LUT calibration, the created LUT file is ready to be manually
loaded into the FSI monitor. To load a software 3D LUT calibration file into an FSI CFE monitor:
1. From the monitor’s on-screen menu, load the default profile (Menu \ System \ Load Profile \
Default). Press Enter to start the process, and confirm with Yes when prompted.
2. Verify that the monitor is in update mode (Menu \ System \ UDisk Mode \ On).
3. Connect the FSI-supplied USB to RJ45 update cable to the monitor GPI port and to a USB port on
your computer. After a short time, the computer will recognize the FSI monitor as a mass
storage device (disc drive), viewable in Mac’s Finder or PC’s My Computer.
4. On your computer, drag and drop the user
x
.dat or user
x
.cfe LUT file to the monitor storage
device. You may load up to three custom LUT files at a time (“user1.dat”, “user2.dat”, and
“user3.dat” or “user1.cfe”, “user2.cfe”, and “user3.cfe”).
5. When the file is finished transferring, on the monitor go to: Menu \ Display Alignment/Color
Management \ Update CFE. Press Enter to start the update process, and confirm with Yes when
prompted. The update process will take approximately 6 minutes per LUT for CFE monitors and
approximately 15 seconds per LUT for CFE2 monitors.
6. When the LUT update is complete, power cycle the monitor.
7. In the FSI monitor’s Display Alignment/Color Management menu, set LUT Bypass to Off.
8. Exit the FSI monitor’s menu.
9. Reenter the menu and access the new custom calibration LUT from the monitor’s Display
Alignment/Color Management menu by selecting: Menu \ Display Alignment/Color
Management \ Color Space \ (USER1, USER2, or USER3).
DONE – Flanders Scientific 3D LUT calibration and setup is complete.
