VPS-2000 USB Drive File Structure

The VPS-2000 Video Pattern Set contains patterns at the four major consumer video

resolutions, 480, 576, 720, and 1080, at both SMPTE video levels and full range PC
levels. It contains grayscale and color patterns at 5% luminance increments, color
patterns at 20% and 25% saturation increments, and a full range of visual evaluation

patterns.
The VPS-2000 USB Drive file structure is outlined below for the 1080 resolution. Though
not shown, the same selection of patterns is also available at each of the other video

resolutions.

01 Patterns

01 CalMAN

01 480
02 576
03 720
04 1080

01 Video Levels 16-235

01 Small Luminance

small window luminance levels

02 Large Luminance

large window luminance levels

03 Full Luminance

full screen luminance levels

04 Small Saturation

small window saturation levels

05 Large Saturation

large window saturation levels

06 Full Saturation

full screen saturation levels

07 Specialty Patterns

visual evaluation patterns

02 PC Levels 0-255
