SOR Single Point RF Level Switch - Manual (Page 11)

Form 830 (03.13) ©SOR Inc. 11/12
Dimensions
A LENGTH
(PER MODEL NUMBER)
116.7
4.59
96.0
3.78
B
C
19.1
0.75
(INACTIVE SHEATH ONLY)
D
INACTIVE SHEATH LENGTH
(PER MODEL NUMBER)
ELECTRICAL
CONNECTION
3/4 NPTF
PROCESS
CONNECTION
SEE TABLE
1
1
Dimensions are for reference only.
Contact the factory for certified drawings
for a particular model number.
Linear = mm/inches
Drawing 0390652
PROCESS CONNECTION
DIM B DIM C
CABLE
PROBE
ALL OTHER
PROBES
CABLE
PROBE
ALL OTHER
PROBES
3/4 NPTM
87.8
3.46
94.1
3.71
205.2
8.08
211.6
8.33
1, 1-1/2, & 2 NPTM
99.7
3.92
97.3
3.83
217.2
8.55
214.8
8.46
FLANGED
158.5
6.24
158.5
6.24
276.0
10.87
276.0
10.87
STILLING WELL N/A
120.0
4.72
N/A
237.5
9.35
NOTES:
1. DIMENSION APPROXIMATE AND BASED
ON A FIVE THREAD ENGAGEMENT.
1
SENSOR STYLE D
BARE
12.7
0.50
SHEATH
15.9
0.63
BARE WITH
STILLING WELL
26.7
1.05
SHEATH WITH
STILLING WELL
26.7
1.05
CABLE
7.90
0.31
INACTIVE SHEATH
15.9
0.63
