Form 1571 (10.13) ©SOR Inc. 5/24

Windowed, Normally-Closed
The 815PT switch

Off
can be configured
 
Windowed, Normally-Open
nine different ways:
 
Windowed, Normally-Closed


Single Point, Normally-Open (Close on Rise/Open on Fall)


Single Point, Normally-Closed (Open on Rise/Close on Fall)


PWM (Pulse Width Modulation), Pulsed Low
 
PWM (Pulse Width Modulation), Pulsed High
 
Dead Band, Normally-Open


Dead Band, Normally-Closed

Single Point, Normally-Open (Close on Rise/Open on Fall)
In this configuration, the switch output will be open when the process pressure
is within a user selectable range and closed when the pressure is outside of these
boundaries. This is designed for applications where there is a known acceptable
operating pressure range.

Windowed, Normally-Open
In this configuration, the switch output will be closed when the process pressure
is within a user selectable range and open when the pressure is outside of these
boundaries. This is designed for applications where there is a known acceptable
operating pressure range.
In this configuration, the switch output will be open for pressures less than the
selected setpoint. The switch output would then be closed for pressures greater
than the setpoint.
