Installation, Back view – Parr Instrument 6755 User Manual
Page 7
Installation
6755
1
w w w . p a r r i n s t . c o m
5
Figure 1
NOTE:
CONNECT UNTERMINATED 493E WITH 328HC BRACKET TO THE MOTOR
OUTPUT RECEPTACLE SECURING IT USING THE SA1332RP06 FASTENER.
6772 Calorimetric Thermometer Back Panel
(SEE NOTE)
DATA LABEL
95F
BACK VIEW
2X SA1332RP06
6-32 X 3/8 RHMS PHILLIPS
6-32 X 3/8 RHMS PHILLIPS
BACK PANEL (REF)
327C2
SA1332RP06
2X SA1140RP04
4-40 X 1/4 RHMS PHILLIPS
493E Plug
with 3280HC Retainer
installed to insulate
from live circuits when
no motor is attached.
