Page 48
13
Drawings
P a r r I n s t r u m e n t C o m p a n y
46
Internal Parts View of 6772 Calorimetric Thermometer
Note:
1262DD Capacitor Bracket and 897E Capacitor not shown for clarity.
BINDING POST, BLACK
A59A4
POWER SUPPLY
BINDING POST, RED
A59A2
6-32 HEX KEPS NUT
(1262DD BRKT MTG)
2X TA030MFP05
3mm X 5mm FHPMS
2X TN1332HL
1940E
327C2
BACK PANEL
ASSEMBLY
