5 Set-up and connection
Pos: 93 / 200 Christ /36 0 GT -BA La bor -Pilot (S TANDARDMODULE) /05 0 Aufstell ung und Anschlus s/05 0-0 011 Aufst ellort (Epsilon ) @ 25\ mod _14 049 8373 912 9_6 8.d ocx @ 1835 23 @ 2 @ 1
5.1 Installation site
Operate the freeze-dryer only in closed and dry rooms.
• Ensure sufficient ventilation. Do not place any paper, cloth, or similar
material behind or under the unit, since otherwise the air circulation will
be impaired.
• Keep a safety distance of at least 30 cm from the wall so that the vents
in the unit remain fully effective.
• The ambient temperature must be in the range of +10°C to +25°C.
• Do not subject the freeze-dryer to thermal stress, e.g. by positioning it
near heat generators.
• Avoid direct sunlight (UV radiation).
Pos: 94 / 010 Unive rsalm odul e/Le erzeil e @ 0\mo d_1 202 116 244 500 _0.d ocx @ 114 @ @ 1
Pos: 95 / 200 Christ /36 0 GT -BA La bor -Pilot (S TANDARDMODULE) /05 0 Aufstell ung und Anschlus s050 -0 020 Ener gieve rso rgun g- --- -- --- --- -- --- -- --- --- -- --- -- --- -- -- @ 25\ mod _14 049 837 4000 8_6 8.d ocx @ 183 537 @ 2 @ 1
5.2 Power supply
Pos: 96 / 200 Christ /36 1 GT -BA La bor -Pilot (PROJEKTE )/Epsilon 2- 4 LSCplu s Stan dar d/05 0 Aufst ellun g un d Anschl uss/0 50- 002 0-0 010 Anschlu ssart E1-4 _2- 4 @ 25\ mod _140 498 473 505 9_6 8.doc x @ 1 860 43 @ 3 @ 1
5.2.1 Connection
DANGER
The operating voltage on the name plate must correspond to the local
supply voltage
CHRIST freeze-dryers are units of safety class I.The freeze-dryers of the
type Epsilon 1-4 LSCplus and Epsilon 2-4 LSCplus have a three-wire
power cord with an IEC C13 connector (see chapter 10 - "Technical data").
An equipotential bonding screw is located on the back below the mains
power input . This equipotential bonding screw can be used to perform an
earth conductor check.
Pos: 97 / 010 Unive rsalm odul e/Le erzeil e @ 0\mo d_1 202 116 244 500 _0.d ocx @ 114 @ @ 1
Pos: 98 / 200 Christ /36 1 GT -BA La bor -Pilot (PROJEKTE )/Epsilon Stan dar d/05 0 Aufst ellung un d Anschl uss/05 0-0 020 -00 20 Sicher ung en b ausei ts Epsilon @ 2 5\m od_ 1404 984 623 550 _68. docx @ 18 566 5 @ 3 @ 1
5.2.2 Customer-provided fuses
Typically, the freeze-dryer must be protected with 16 Amp G fuses that are
to be provided by the customer.
Pos: 99 / 010 Unive rsalm odul e/Seite nwechs el @ 0 \mo d_1 202 116 244 312_ 0.d ocx @ 105 @ @ 1
