Freeze-dryer EPSILON 1-4 LSCplus
Freeze-dryer EPSILON 2-4 LSCplus

10 Technical data

102

Version 04/2014, Rev. 1.4 of 09/12/2014 • sb

Translation of the original operating manual

Connection requirements

Electrical connection:

1 x 230 V / 50 Hz
(other supply data on request)

Protection class:

IP-Code according to DIN 60529:

Nominal power:

1.0 kVA

1.9 kVA

Nominal current (without vacuum pump): 4.5 A

8.5 A

Mains fuse:

12 A

14 A

Equipment connections

Vacuum connection:

Small flange connection DN25KF
(ISO 28403, DIN 2861)

Aeration valve:

Hose nozzle DN4

(outside diameter 8 mm max)
max. 0.2 bar overpressure

Hose nozzle DN4

(outside diameter 8 mm max)
max. 0.2 bar overpressure

Mains input:

IEC C13 connector

Data interface (LAN):

RJ 45

Special equipment: water cooling
system

Part number:

112993

112994

Water feed flow temperature:

+15°C to +20°C

Water return flow temperature:

25°C max.

Water temperature difference:

10K max. with +15°C feed flow
temperature
5K max. with +20°C feed flow

temperature

10K max. with +15°C feed flow
temperature
5K max. with +20°C feed flow

temperature

Cooling water pressure:

10 bar max.

Differential pressure between feed flow

and return flow:

1.5 bar max.

Volumetric flow rate:

0.13 m

/h max.

0.20 m

/h max.

Heat dissipated by cooling water:

1.1 kW

1.6 kW

Cooling water feed flow connection:

R3/4" with hose nozzle DN 13

Cooling water return flow connection:

R3/4" with hose nozzle DN 13

Option: cooling water flow controller
(factory setting):

12 bar (refrigeration unit, high
pressure side)
